SD Laser E10 fiber laser cutting machine
Shipping time :
3 months
Request for quotation
Ultra high speed and precision in a flatbed laser cutter! The E10 is not only the fastest laser cutter in our range – 280m/min – but also exceptional precision is achieved thanks to its solid marble table and top-quality CNC components. Although it can also be ordered with high laser power, making it universally suitable for cutting thicker materials, its high level of precision, acceleration and speed make it particularly advantageous for super-fast and precise cutting of thin sheets.
Extreme acceleration and speed
Our E10 fiber laser machine is capable of up to 5G acceleration and a maximum idle speed of 280m/min. This is thanks to the American Kollmorgen linear motors, the solid marble table and top-quality CNC drive components. Due to the direct drive, there is no mechanical backlash, fewer power transmission drive elements and thus super-fast movement is achieved. The productive speed can be utilized for thin sheets, but thanks to the high-power laser source, the E10 laser cutter is also excellent for laser cutting thick sheets. The high acceleration is also supported by the lightweight carbon fiber bridge, which is lighter than steel, with greater structural rigidity.
Exceptional Precision
The solid marble bed provides extreme precision and stronger stability than any conventional welded or cast steel worktable. This precision base provides excellent thermal and geometric stability. With our E10 laser cutter, you can combine precision cutting with extraordinary acceleration and speed.
Carbon Fiber X-axis Bridge Beam
The thermal expansion coefficient of carbon fiber material is extremely low, so it is less affected by temperature fluctuations in the machining environment. This effectively prevents accuracy deviations caused by thermal deformation. The high-speed, vibration-free movement significantly increases productivity and machining accuracy. The beam is more than 50% lighter than traditional metal beams, and all sheet metal parts on the beam are made of aluminum alloy. The beam is light in weight, so when driven by a linear motor, it has low inertia, can accelerate quickly, and has high rigidity. This reduces vibration and enables precise cutting.
High Quality components
Top performance is matched with top quality components, which is also true for our E10 fiber laser cutter. Instead of the traditional servo motor drive, our laser cutter has a direct drive with American KOLLMORGEN linear motors. The Y-axis linear guide rail system includes SCHNEEBERGER roller guide carriages designed for 100,000 operating hours. Two-row system, 6 carriages with excellent load distribution. The soul of our machine is the laser source Raycus, which is the market leader in fiber laser sources and we have trusted this brand in our company for more than 10 years, which is higher quality compared to Max, JPT and other cheaper Chinese laser sources. The control system and laser cutting head are BOCHU, which is also one of the most popular and proven brands in this category of laser cutters.
Zoned active extraction system
The extraction system of the E10 laser machine now uses the new zoned technology, which is much more efficient than traditional single-point extraction. One element of the system is the pressurized space, which, with the help of fans and the extractor, forces the air from top to bottom, along with dust and fumes. The next important point of the system are the active, pneumatically operated butterfly valve zones, which are always open at the current location of the laser cutting, thus optimizing the extraction efficiency.
Slag/waste discharge system
The chain waste discharge conveyor track not only discharges solidified slag and falling waste from under the machine, but also helps with the extraction efficiency by partially closing the lower space. This solution also simplifies the periodic maintenance of the machine, thus increasing productivity.
Maximum quality and occupational safety
The E10 is fully enclosed and meets the strictest industry standards both structurally and in terms of electronics, so it can be ordered with TÜV certification if required. The viewing windows are OD4+ class laser-protective industrial glass, which is typically not found in competing fiber laser cutting machines in this category.
Pneumatic table height adjustment
Traditional, common table change mechanisms (we use them in several of our own models) do not include table lifting, but the two tables are located on two levels and are moved in and out in one line, without vertical movement, and the level difference is solved by the larger Z movement range of the laser head. In the case of the E10, since high-precision accuracy can be achieved, all this at enormous speed and acceleration, the significant reduction in the Z movement range of the laser head contributes to more stable operation. Thus, the precise head and the CNC mechanism do not have to adapt to the height of the table, but the table is raised pneumatically to the appropriate level before starting work.
BOCHU, the market leader in industrial control for fiber laser cutting machines
The EtherCat control system of the FSCUT1000, 2000, 4000 and 8000 (depending on configuration) has been developed for ultra-high-performance laser cutting machines. The industry-standard bus system provides high-speed network connectivity, and the user interface with multi-touch display is clean and user-friendly.
Raycus, the market leading laser source brand
Our company is committed to Raycus laser source instead of Max, BWT or other cheaper Chinese laser sources. Raycus has service centers in Germany and Italy, while other Chinese brands require the laser source to be sent back to China if it fails, which is expensive and time-consuming. Raycus not only provides a more reliable warranty and service background, but also a longer lifespan. So choose the reliable SD Laser fiber laser cutting brand with a reliable CE certified Raycus laser source!
Optional TÜV certification for European requirements
There are almost no Chinese laser cutting equipment on the market that has both CE and TÜV certification. We are proud that all SD Laser fiber laser cutters meet the highest requirements for reliability and safe operation. Only the TÜV certificate guarantees, for example, that the housing of your laser cutter has the appropriate OD4+ standard glazing, ensuring the appropriate protection.
18 years, lots of machine installation and experience
We have now become a leading supplier in Hungary when it comes to industrial laser cutting installations. We have installed more than 60 industrial fiber laser cutters and more than 500 industrial CO2 laser engravers since 2005. Thanks to our appropriate organizational structure and processes, as well as our Full Service service, all of our laser cutting machines are still operating without problems at our customers' sites.
Full Service: Needs assessment and site visit, quotation, logistics services, machine installation and commissioning, training and fast service.
Details
Product images and features shown may include optional items!
Specifications
Working area: 3000x1500mm
Table changer: Yes (2pcs)
Laser power: 3kW – 20kW
Positioning accuracy: 0.015mm/m
Return accuracy: 0.01mm/m
Maximum movement speed: 280m/min*
Maximum acceleration: 5G*
Z axis movement range: 120mm
Control system: Bochu
Laser head: Bochu
CNC drive: Rack and pinion drive with German and Japanese components
Nesting software: Standard equipment
*No-load speed and acceleration values! The actual maximum cutting speed depends on the power of the laser source, the material and its thickness!
