SD Laser S10 fiber laser cutting machine
Shipping time :
3 months
Request for quotation
Our S10 series is based on the entry-level open S5, but it is an excellent transition between fully enclosed flatbed laser cutters and open, cheaper laser cutters. Its advantage is that only the necessary moving parts and the laser are enclosed, so it not only achieves the same level of safety as fully enclosed equipment, but also takes up less space, is cheaper and has the highest TÜV certification. It is available with tables of 3000x1500mm and 6000x2000mm and with laser power from 3kW to 20kW. The S10 laser machine contains further new developments. Scroll down for details!
Enclosure only where needed!
Our S10 laser cutter is unique in its category because it combines the advantages of cheaper flatbed, open fiber laser cutters and fully enclosed laser cutters. Only the necessary moving bridge and laser light area are enclosed, ensuring maximum work safety while saving significant space. Unlike our S5 machine, the S10 is also available with TÜV certification, which is also a special advantage in its category.
Safer and more cost-effective machine body
The S10 X-axis bridge has a side mount, which is also unique in its category. Traditional CNC mechanical components, such as rack and pinion drives, are typically placed on top of the machine body edge. Side mount not only reduces the machine's footprint, but more importantly, it eliminates the need for the usual metal or plastic accordion or telescopic protection that serves as mechanical protection. Since the drive components, the linear rail, are located on the side, neither the laser nor the plate are exposed to damage from loading and unloading.
New heat-resistant coating
The renewed composite refractory brick coating puts our S10 laser machine on a higher technical and quality level. The new material provides adequate fire resistance, heat resistance, and is also more resistant to slag adhesion, which also reduces periodic maintenance work. A few years ago, only our top-performance models received this option, but today it is standard equipment on our S10 flatbed laser cutter.
BOCHU, the market leader in industrial control for fiber laser cutting machines
The EtherCat control system of the FSCUT1000, 2000, 4000 and 8000 (depending on configuration) has been developed for ultra-high-performance laser cutting machines. The industry-standard bus system provides high-speed network connectivity, and the user interface with multi-touch display is clean and user-friendly.
Raycus, the market leading laser source brand
Our company is committed to Raycus laser source instead of Max, BWT or other cheaper Chinese laser sources. Raycus has service centers in Germany and Italy, while other Chinese brands require the laser source to be sent back to China if it fails, which is expensive and time-consuming. Raycus not only provides a more reliable warranty and service background, but also a longer lifespan. So choose the reliable SD Laser fiber laser cutting brand with a reliable CE certified Raycus laser source!
TÜV certified for European requirements
There are almost no Chinese laser cutting equipment on the market that has both CE and TÜV certification. We are proud that all SD Laser fiber laser cutters meet the highest requirements for reliability and safe operation. Only the TÜV certificate guarantees, for example, that the housing of your laser cutter has the appropriate OD4+ standard glazing, ensuring the appropriate protection.
18 years, lots of machine installation and experience
We have now become a leading supplier in Hungary when it comes to industrial laser cutting installations. We have installed more than 60 industrial fiber laser cutters and more than 500 industrial CO2 laser engravers since 2005. Thanks to our appropriate organizational structure and processes, as well as our Full Service service, all of our laser cutting machines are still operating without problems at our customers' sites.
Full Service: Needs assessment and site visit, quotation, logistics services, machine installation and commissioning, training and fast service.
Details
Product images and features shown may include optional items!
Specifications
Working area: 3000x1500mm, 2000x6000mm
Table changer: None (1 fixed table)
Laser power: 3kW – 20kW
Positioning accuracy: 0.03mm/m
Return accuracy: 0.02mm/m
Maximum movement speed: 100m/min
Maximum acceleration: 1.2G
Z axis movement range: 120mm
Control system: Bochu
Laser head: Bochu
CNC drive: Rack and pinion drive with German and Japanese components
Nesting software: Standard equipment
