SD Laser S5 fiber laser cutting machine
Shipping time :
3 months
Request for quotation
The S5 is the entry-level series in our range. Entry-level does not mean compromising on technical level and cutting quality! Our S5 flatbed laser cutter features the same high-quality CNC main parts and the market-leading Raycus laser source as our larger models. It has a fixed table, is compact, has a small footprint and is unbeatable in price, making it an ideal choice for small businesses!
Compact, space-saving fiber laser cutter
The S5 is an open sheet fiber laser cutter, which despite its open design can be operated without problems under appropriate work safety conditions. After 10 years of experience, the S5 is the latest generation, which represents a higher level of technical quality than cheaper Chinese laser cutters. German and Japanese rack and pinion drive main parts, Raycus laser source, Bochu control and laser cutting head and many quality components that ensure multi-shift operational usability and long service life.
Efficient sheet metal handling
Our laser cutter features ball-bearing material feed rollers, which not only make it easier for the machine operator to load the sheet metal, but also protect both the sheet and the machine body.
Optimal dust and fume extraction
The machine extracts dust and fume directly at the point of origin, therefore ensuring extremely high extraction efficiency. The system has a simple structure, low cost and low energy consumption. This design reduces dust and fume contamination of the equipment, thereby increasing the service life of the machine by up to 2-3 times, while reducing maintenance costs. At the same time, it enables cost reduction, better quality and more environmentally friendly operation.
BOCHU, the market leader in industrial control for fiber laser cutting machines
The EtherCat control system of the FSCUT1000, 2000, 4000 and 8000 (depending on configuration) has been developed for ultra-high-performance laser cutting machines. The industry-standard bus system provides high-speed network connectivity, and the user interface with multi-touch display is clean and user-friendly.
Raycus, the market leading laser source brand
Our company is committed to Raycus laser source instead of Max, BWT or other cheaper Chinese laser sources. Raycus has service centers in Germany and Italy, while other Chinese brands require the laser source to be sent back to China if it fails, which is expensive and time-consuming. Raycus not only provides a more reliable warranty and service background, but also a longer lifespan. So choose the reliable SD Laser fiber laser cutting brand with a reliable CE certified Raycus laser source!
18 years, lots of machine installation and experience
We have now become a leading supplier in Hungary when it comes to industrial laser cutting installations. We have installed more than 60 industrial fiber laser cutters and more than 500 industrial CO2 laser engravers since 2005. Thanks to our appropriate organizational structure and processes, as well as our Full Service service, all of our laser cutting machines are still operating without problems at our customers' sites.
Full Service: Needs assessment and site visit, quotation, logistics services, machine installation and commissioning, training and fast service.
Details
Product images and features shown may include optional items!
Specifications
Working area: 3000x1500mm
Table changer: None (1 fixed table)
Laser power: 1.5kW – 6kW
Positioning accuracy: 0.03mm/m
Return accuracy: 0.02mm/m
Maximum movement speed: 110m/min
Maximum acceleration: 1G
Z axis movement range: 120mm
Control system: Bochu
Laser head: Bochu
CNC drive: Rack and pinion drive with German and Japanese components
Nesting software: Standard equipment
